T&S EasyInstall Pre-Rinse
T&S EasyInstall Pre-Rinse
Availability： Lead time provided upon request
Model No.： B-0113-ADF12-B
Inlet Connection: 5/8" copper tubing or 1/2" NPSM male
Material: Brass
Spout Length: 12 inches (304.8 mm)
Spout Flow Rate: 5.57 GPM (21.08 L/min)
Spout Outlet Type: Laminar flow device
Maximum Pressure: 125 psi (8.62 bar)
Minimum Pressure: 20 psi (1.38 bar)
Spray Valve: Model B-0107 (1.15 GPM / 4.35 L/min)
Spray Valve Flow Rate: 1.15 GPM (4.35 L/min)
Maximum Temperature: 140°F (60°C)
Minimum Temperature: 40°F (4.44°C)
Swing Spout with Flow Regulator：Series 1 design for smooth directional control and optimized flow.
Flexible Stainless Steel Hose：Equipped with gray heat-resistant handle and hold-down ring for ergonomic and safe use.
Wall Bracket：6-inch (152.4 mm) adjustable bracket for enhanced stability.
Lever Handles with Color-Coded Indicators：Easy identification of hot and cold water, ensuring user-friendly operation.
Mounting Style：Single-hole deck-mount mixing faucet for streamlined installation.
Features EasyInstall chrome-plated brass body for simplified setup.
Quarter-turn Eterna compression cartridge with spring check valves to prevent cross-flow.
Polished chrome-plated brass main body / Tubular swing spout / Chrome-plated brass auxiliary faucet body, riser, and spray valve / Stainless steel hose / Chrome-plated metal handles
