DAIKIN Inverter Condensing Unit
DAIKIN Inverter Condensing Unit
Availability： Lead time provided upon request
Model No.： URC060MB7-P
Dimensions: 995 × 425 × 1362 mm
Net Weight: 138.5 kg
Max Cooling Capacity: 14.57 kW
Max Power Input: 10.5 kW
Refrigerant: R404A
Noise Level: 56 dB(A)
Fan Diameter: 551 mm
Air Volume: 7400 m³/h
Receiver Tank Volume: 3.8 × 2 L
IceWind Series
Inverter Condensing Unit
Backed by Daikin’s century of engineering expertise and advanced core technologies, the IceWind Series inverter condensing units are built for exceptional reliability and performance. Featuring full inverter control, a high-efficiency condenser, and proprietary control algorithms, they ensure precise temperature regulation, lower energy consumption, and quiet operation.
Designed for a wide range of commercial applications, including convenience stores, supermarkets, cold storage facilities, and low-temperature work areas, the IceWind Series performs consistently in ambient temperatures from –30°C to +15°C. It offers dependable refrigeration for frozen foods, beverages, fresh produce, and meat products.
DC Inverter Scroll Compressor
Featuring an asymmetric scroll design and intelligent inverter control, the DC compressor ensures stable performance across load variations. Smooth modulation minimizes start-stop cycles, reducing energy consumption and extending system life—all while operating at low noise levels.
DC Inverter Fan Motor
Engineered for high efficiency and precision control, the DC inverter fan motor automatically modulates speed in response to ambient temperature conditions. This stepless adjustment ensures quieter operation, enhanced energy savings, and optimal airflow performance under all load conditions.
Optimized Heat Exchanger Design
Internally grooved copper tubing increases refrigerant turbulence for improved heat transfer, while hydrophilic, window-cut aluminum fins expand surface area for greater cooling efficiency. The integrated subcooling system enhances output, and a patented airflow structure ensures stable performance—even in high ambient conditions.
| # | Name | Upload date | Description | Download |
|---|---|---|---|---|
| 1 | 冰鋒系列變頻冷凝機組 | 2025-07-07 | 冰鋒系列變頻冷凝機組 |
